TruCheck 75 - 750 lbf.ft

Where to Buy

Enlarge

This product is now obsolete, for details of the new, re-engineered model please click here

The TruCheck is for click type torque wrenches and comes with a single measurement unit, lbf·ft. There is only one button on the device and that is to zero the display. Operation is simplicity itself and it is virtually impossible to go wrong!

Part number: 43237
EAN Bar Code: -
NATO number: -
Accuracy: -
Operates between:

75.00 - 750.00 lbf·ft

Compare This Product

Features

Supplied with a Traceable Calibration Certificate.
Allows torque tool performance to be monitored and tools kept in peak condition.
Basic version has no settable options. Ideal for non-expert users.

Technical Specification

Estimated Dimensions: 145.5mm (d) x 175mm (w) x 85mm (h)
Accuracy: +/-1%, +/-1 digit over the stated operating range.
Display: 4 Digit, 7 segment LED. With update rate of twice per second (2Hz)
Temp Range - Operating: +5ºC to +40ºC
Temp Range - Storage: -20ºC to +70ºC
Auto Reset Hold Time: 2 seconds
Electromagnetic Compatibility (EMC) Directive: In conformance with EN 61326:1997
Weight (for shipping): 4.8 Kg
Drive Size: 27mm male hexagon. Supplied with 3/4" square drive socket.
Optional UKAS accredited calibration is from 10% to 100% of full scale

Operators Handbook

34384EN.pdf

Catalogue

Pg65-67.pdf
